18.3 Tool and tool magazine table.
This table defines the tools available and the data associated with each one of them. The
tool list is common to the whole system, i.e. is common to all the available magazines. Once
the tools have been defined, they may be distributed in the various magazines.
18.3.1 Vertical softkey menu.
The options shown for the tool table are. Bear in mind that the table is divided into two panels.
There are options that are valid for both panels and options that are only available on one
of them.
Softkey. Description.
Show more options on the softkey menu.
Change the units for data display. The softkey highlights the units currently selected
(millimeters or inches).
The selected units are only valid for displaying data. For programming, the CNC assumes
the units defined with the active function G70 or G71, or, when not programmed, the units
set by the machine manufacturer (INCHES parameter).
The CNC will display this softkey or not depending on how machine parameter
MMINCHSOFTKEY has been set.
Search for a text on a tool list. See "18.1.2 Search for a text in the tables" on page 295.
Add a new tool to the list. This icon is only available for the tool list.
Remove a tool from the list. A tool cannot be deleted if it is in the tool magazine. This icon
is only available for the tool list.
Delete the data where the cursor is. When deleting a data, it assumes its default value.
This icon is only available for tool data.
Configure the data shown in the tool table. This icon is only available for tool data.
It initializes the tool table. Initializing the tables eliminates all the tools from the list. It also
initializes the active-tools table and the magazine tables because the available tools have
been erased. The CNC will request confirmation of the command.
Saves the table data in a file. See "18.1.3 Save and load the tables" on page 296.
Recall the table data previously saved in a file. Bear in mind that loading the tool table
initializes the magazine tables and the active-tools table. See "18.1.3 Save and load the
tables" on page 296.
Print the table in the pre-determined printer or save it as a file (prn format) at the CNC.
See "18.1.4 Printing the tables" on page 298.
