18.9.2 Load / unload a tool to / from the tool changer arm
Nor can the tools that are in the holders of the tool changer arm be inserted in the spindle.
To load or unload one of these tools:
1 Press the softkey associated with the operations with the changer arm.
2 Define the tool number in the positions of the tool changer arm.
When using a two-holder changer arm, there may not be tools in the spindle and in the
second holder of the changer arm at the same time.
3 Press [ENTER] to update the table.
A tool is loaded/unloaded to/from the claws (holders) of the changer arm using the vertical
softkey menu. To insert a tool in the holders of the changer arm (when available), it must be
placed in the magazine. Ground tools cannot be placed in the claws (holders) of the tool
changer arm.
