3.9 Dialog boxes
The dialog boxes consist of the following elements. All the actions may be carried out with
the mouse or via keyboard.
Using the keyboard
The data of the dialog boxes are defined via keyboard as follows.
• Using the [CTRL]+[TAB] combination, it is possible to select different panels of the dialog
box.
• The [TAB] key moves the cursor through the elements of the box.
• The [SPACE] key activates the selection boxes, selects an options and selects a color
from the color pallet.
• The [ENTER] key presses the button that is selected.
• The [ESC] key closes the dialog box without accepting the changes.
• On the drop lists, the desired option may be selected using the keys on the keyboard.
• The arrow keys [][][][] move the cursor over the color pallet and over the options
of a list.
• Selection panels.
It selects among the different option groups within the same dialog
box.
• Drop list.
It selects an option from a list. Clicking on the right icon, the list
expands.
• Selection box.
It activates an option.
• Option selection.
It selects an option from a group. Selecting one cancels the
previous one.
• Color pallet.
Select a color.
• Selection buttons.
They access a group of options or close the dialog box.
After making the changes, the dialog boxes are closed using one
of the buttons that let you accept or reject the changes made.
