Operating manual.
CNC 8060
CNC 8065
SETUP ASSISTANCE
22.
Oscilloscope
·407·
(REF: 1807)
22.1.5 Machine parameter editing.
Here is a list of machine parameters and variables of the drive that may be modified from
the oscilloscope.
Axis or spindle machine parameters that may be edited
The table indicates the parameters that will be assumed at the beginning of the next block.
For this to be so, the instruction "#SYNC POS" must be programmed after each motion block.
The new values are assumed by the CNC after pressing [ENTER] and they are maintained
until the unit is turned off. Once the setup is completed, the changes must be saved so they
can be effective next time the CNC is turned on.
Use the "Validate" softkey to save the data. The CNC saves the new values in the CNC tables
and/or in the drive tables accordingly.
CNC Drive Associated variable Update
PRELOAD MPG.PRELOAD[tandem] Immediate
PRELFITI MPG.PRELFITI[tandem] Immediate
TPROGAIN MPG.TPROGAIN[tandem] Immediate
TINTIME MPG.TINTIME[tandem] Immediate
TCOMPLIM MPG.TCOMPLIM[tandem] Immediate
INPOSW MPA.INPOSW.[gamme].axis Immediate
BACKLASH PP58 MPA.BACKLASH.[set].axis Immediate
G00FEED MPA.G00FEED.[set].axis Beginning of next block
MAXVOLT MPA.MAXVOLT.[set].axis Immediate
PROGAIN PP104 MPA.PROGAIN.[set].axis Immediate
FFGAIN PP216 MPA.FFGAIN.[set].axis Immediate
MANFFGAIN PP216 MPA.MANFFGAIN.[set].axis Immediate
ACFWFACTOR MPA.ACFWFACTOR.[set].axis Immediate
ACFGAIN PP217 MPA.ACFGAIN.[set].axis Immediate
MANACFGAIN PP217 MPA.MANACFGAIN.[set].axis Immediate
LACC1 MPA.LACC1.[set].axis Beginning of next block
LACC2 MPA.LACC2.[set].axis Beginning of next block
LFEED MPA.LFEED.[set].axis Beginning of next block
ACCEL PP42 MPA.ACCEL.[set].axis Beginning of next block
DECEL PP42 MPA.DECEL.[set].axis Beginning of next block
ACCJERK MPA.ACCJERK.[set].axis Beginning of next block
DECJERK MPA.DECJERK.[set].axis Beginning of next block
ESTDELAY MPA.ESTDELAY.[set].axis Immediate
SERVOOFF MPA.SERVOOFF.[set].axis Immediate
MINANOUT MPA.MINAOUT.[set].axis Immediate
BAKANOUT PP2 MPA.BAKANOUT.[set].axis Immediate
BAKTIME PP3 MPA.BAKTIME.[set].axis Immediate
PEAKDISP PP14 MPA.PEAKDISP[set].axis Immediate
REVEHYST PP15 MPA.REVEHYST[set].axis Immediate
FBMIXTIME PP16 MPA.FBMIXTIME.axis Immediate
FLIMIT MPA.FLIMIT.axis Immediate
SLIMIT MPA.SLIMIT.axis Immediate
