Operating manual.
CNC 8060
CNC 8065
20.
PLC
Editing in contact (ladder) language (softkeys).
·358·
(REF: 1807)
20.5.6 Softkey "Find".
This softkey is used to find a text or a block by its number.
Find "Find"
When selecting this option, the CNC shows a dialog box requesting the block number or the
text to look for. When defining a text search, certain options may also be defining that allow:
A Select the types of fields in which to search.
B Ignore uppercase and lowercase.
C Consider the text to find as a whole word.
After defining the search options, press [ENTER] to do the search or [ESC] to cancel it.
Pressing [ENTER] positions the cursor in the first field that matches the search parameters.
Find "Find next"
It positions the cursor in the next field that matches the search parameters.
Find "Find previous"
It positions the cursor in the previous field that matches the search parameters.
20.5.7 Softkey "Customize".
It is used for personalizing the appearance (color, font, etc.) and properties of the editing
window.
After defining the new look, use the cursor to select one of the buttons here below to accept
or ignore the changes made and press [ENTER]. The dialog box may also be closed directly
without accepting the changes by pressing [ESC].
