Operating manual.
CNC 8060
CNC 8065
16.
MDI/MDA MODE
Block history.
·282·
(REF: 1807)
16.3 Block history.
Save blocks in block history.
The MDI(MDA mode saves into history all the blocks executed correctly. Press [ENTER] to
save a block in the history without executing it. If it is a new block, it will be added to the history
whereas if it is modified block, it will replace the previous one in the history.
Save the blocks as a program
To save the block history as an independent program, press the "Save" softkey and the CNC
will show a list of the programs saved at the CNC.
1 Write the program name in the bottom window. To replace an existing program, select
it from the list.
2 Press [ENTER] to save the program or [ESC] to return to the MDI mode without saving
the program.
