Fagor CNC 8065 User Manual

Operating manual.
CNC 8060
CNC 8065
PLC
20.
Program monitoring
·361·
(REF: 1807)
20.6.2 Softkey menus. Monitoring in contact (ladder) language.
In a program edited in contact (ladder) language, the softkey menu shows the following
options.
View.
View "Zoom +"
Increase the size of the font as well as the height and width of the contacts.
View "Zoom -"
Reduce the size of the font as well as the height and width of the contacts.
View "Cell +"
Increases the width of the contacts.
View "Cell -"
Reduce the width of the contacts.
Marks.
Marks "Set / remove"
Place or remove a mark on the block where the cursor is located.
Marks "Next mark"
Place the cursor on the next marked block.
Marks "Previous mark"
Place the cursor on the previous marked block.
Marks "Remove all"
Remove all the marks.
Find
This softkey is used to find a text or a block by its number.
Find "Find"
When selecting this option, the CNC shows a dialog box requesting the block number or the
text to look for.
Find "Find next"
This option positions the cursor in the next field that matches the search parameters.
This softkey toggles the display between the mnemonic language and the contact language
(ladder diagram). The softkeys of the horizontal menu change according to the selected
language.
This softkey may be used to enlarge or reduce the size of the contacts and of the text. When
selecting this option, the softkey menu shows the available options. To return to the main
menu, press the key for the previous menu.
BACK
This softkey may be used to add or remove follow-up marks in the program. When selecting
this option, the softkey menu shows the available options. To return to the main menu, press
the key for the previous menu.
BACK
