Operating manual.
CNC 8060
CNC 8065
TOOL AND MAGAZINE TABLE
18.
Tool table
·299·
(REF: 1807)
18.2 Tool table
The CNC offers two tool tables. Use the following softkeys to select each one of them.
Tool table (full mode)
The table is divided in two panels. The left panel shows the list of the available tools and the
right panel shows the data of the tool selected on the list.
This table may be used to set all the tool data. It is also possible to add or remove tools and
offsets from the table.
Tool table (simple mode)
The table shows the list of tools with most common data. This table can only be used to set
some tool data. Unlike the full mode, the simple mode does not allow adding or removing
tools or offsets from the table.
Softkey Table
Softkey available when the tool table is selected in simple mode, it toggles
to full mode.
Softkey available when the tool table is selected in full mode, it toggles
to simple mode.
