Operating manual.
CNC 8060
CNC 8065
21.
MACHINE PARAMETERS
Appearance of the machine parameter tables
·388·
(REF: 1807)
21.1.1 Softkey menus.
Vertical softkey menu.
Softkey. Description.
Show more options on the softkey menu.
Toggle between the two types of units used to represent the parameters that depend on
those units (coordinates, feedrates, etc.). The softkey highlights the units currently
selected (millimeters or inches).
The CNC will display this softkey or not depending on how machine parameter
MMINCHSOFTKEY has been set.
Initialize the table. It resets all the parameters to their default values. The CNC will request
confirmation of the command.
Search a text or a value in the table. When selecting this option, the CNC shows a dialog
box requesting the text to be found.
Validate the table data. If there is no table selected, all the data of all the tables will be
validated.
This table is necessary after changing a data. In certain cases, the CNC will have to turned
off and back on in order for the data to be validated.
Save the values of the table into a file. If there is no table selected, all the data of all the
tables will be saved.
Restore the values of the table previously saved into a file. If there is no table selected,
all the data of all the tables will be recalled.
Print the table in the pre-determined printer or save it as a file (prn format) at the CNC.
Activate the TEACH-IN work mode in order to set the leadscrew and cross compensation
tables.
Export the cross compensation and leadscrew error compensation tables out to an ASCII
file. The files will have the extension mp.
Import the cross compensation and leadscrew error compensation tables that were
previously saved in a file.
