Operating manual.
CNC 8060
CNC 8065
18.
TOOL AND MAGAZINE TABLE
Tool and tool magazine table.
·302·
(REF: 1807)
18.3.2 The tool list
The tool list appears on the left panel of the tool table. The list shows the available tools and
their position. The CNC updates data of the list every time a tool change is carried out.
Tool number
The tool number is assigned automatically when adding the tool to the list and may be
modified by the user in the data window.
Tool name
Name identifying the tool defined by the user in the data window. It may be edited directly
on the list.
Tool position
It indicates the position of the tool, in a magazine, in the spindle or in the claws of the tool
changer arm.
C1-C4 It is in one of the spindles.
M1-M4 It is in one of the magazines. In this case, it also indicates its magazine
position.
CH1-CH2 It is in the holders of the tool changer arm.
If none of these positions is indicated, it means that it is a ground tool. Ground tools are not
stored in the magazine and are loaded manually when requested.
How to move around on the tool list
Copy the data of the offset being displayed onto the clipboard. The data saved may be
pasted to a new offset.
Paste the offset data that is saved on the clipboard.
Softkey. Description.
Key. Meaning.
Scroll list up and down line by line.
Move the cursor page by page through the list.
Move the cursor to the beginning or end of the list.
Access the data of the selected tool.
