Fagor CNC 8065 - Configuring the Profile Editor. Displayed Area

Operating manual.
CNC 8060
CNC 8065
PROFILE EDITOR
11.
Configuring the profile editor. Displayed area.
·217·
(REF: 1807)
11.4 Configuring the profile editor. Displayed area.
The softkey menu of this screen may be used to modify the zoom of the graphics area. When
accessing the "display area" menu, the softkey menu shows the following options:
When at the editor no menu is active to edit data or select elements, these options may be
applied with their corresponding hotkeys. See
"Keyboard shortcuts." on page 205.
11.5 Configuring the profile editor. Define the work plane.
The softkey menu of this screen may be used to modify the axes of the plane and their
directions. At the lathe model, the direction and position of the axes are defined by machine
parameter GRAPHTYPE. When accessing the plane menu, the softkey menu shows the
following options:
11.6 End the session at the editor.
The "End" softkey ends the profile editing session. Before exiting the profile editor, it will offer the option
to save or not the edited profile.
Softkey. Meaning.
Zoom +
Zoom -
Enlarge or reduce the display area.
Optimum area Select the best zoom, i.e. it places the profile in the center of the graphics
window and selects the best zoom possible to show the whole profile.
Part zero Keeps the part zero visible at all times.
Autozoom Activate autozoom. When applying Autozoom, every time a new section is
inserted which goes beyond the screen, the profile will automatically be
centered and zoomed in or out to show the whole profile. This way, it will show
the whole profile again.
Validate Confirm the changes made.
Softkey. Meaning.
Abscissa axis Select the abscissa axis.
Abscissa direction Select the direction of the abscissa axis.
Ordinate axis Select the ordinate axis.
Ordinate direction Select the direction of the ordinate axis.
Validate Confirm the changes made.
Softkey. Meaning.
Save profile Insert the profile in the program and exit the profile editor. If the profile
has been resolved, the CNC will insert it in the part program that is
being edited. If the editor cannot resolve the profile due to lack of
data, the CNC will issue the relevant message.
Do not save profile Do not insert the profile in the program and it exit the profile editor.
Continue Do not insert the profile in the program and continue editing the
profile.
