Operating manual.
CNC 8060
CNC 8065
TOOL AND MAGAZINE TABLE
18.
Presentation of the tool tables and magazine tables.
·295·
(REF: 1807)
18.1.2 Search for a text in the tables
It is possible to search for a text or a value in the list of tools and magazine positions. The
search is carried out from the vertical softkey menu.
To start or resume the search, press [ENTER] and the focus will position on the first match
found. Every time one of the icons is pressed, it offers the option to search for the next match
or to define a new search. The search may be canceled by pressing the [ESC] key.
Define the search criteria.
Every time one of these icons is pressed, it shows a dialog box to define the search criteria.
The following may be defined in this dialog box:
• The text or value to search for.
• The beginning point of the search, namely either from the beginning of the table or from
the cursor position.
This icon starts the search. Once the icon has been pressed, the CNC will display
a dialog box to define the search criteria. The defined criteria is maintained until
a new one is defined.
This icon is shown when a search criteria has been defined; it makes it possible
to search for the next match using the current search criteria.
Key. Meaning.
Move the cursor.
It selects an option from a group.
Start the search.
Cancel the search and close the dialog box.
