26.2.3 Adapting a type 3 kinematics to a type 50 kinematics.
The first column indicates the parameters of the vector kinematics and the second column
the value or parameter of the equivalent type 3 kinematics. Define the values of the second
column with the TDATA parameters of the first column (vector kinematics).
Type 50 Value or equivalent parameter for type 3 kinematics.
TYPE 50
TDATA1 TDATA2
TDATA2 TDATA14
TDATA3 TDATA15
TDATA4 1
TDATA5 0
TDATA6 0
TDATA7 TDATA8
TDATA8 TDATA10
TDATA9 0
TDATA11 0
TDATA12 0
TDATA13 TDATA4
TDATA14 0
TDATA15 1
TDATA16 0
TDATA17 TDATA9
TDATA18 TDATA11
TDATA19 0
TDATA21 TDATA5
TDATA22 TDATA3
TDATA23 TDATA1
TDATA24 0
TDATA25 0
TDATA26 1
