CNC 8060
CNC 8065
17
·283·
(REF: 1807)
USER TABLES
17.1 User table presentation.
The user tables cover the following tables. The various tables may be selected using the
horizontal softkeys.
• Zero offset table. There is a table for each channel.
• Clamp tables (fixtures). There is a table for each channel.
• Table of global parameters. There is a table for each channel.
• Table of local parameters. There are seven tables for each channel, one table per nesting
level (7 levels).
• Table of common parameters. The table is common to all the channels.
Some tables are common to all the channels and others belong to each channel. In this case,
by default, they show the ones of the active channel; but it is possible to access those of any
other channel from the vertical softkey menu.
The zero offset tables and fixture offset tables are common to all the channels; however, in
each channel they show the axes of that channel. When applying an offset in a channel, it
is only applied to the axes that are part of the channel at the time. In order to activate a fixture
zero or part zero offset, those values must be previously stored in the relevant CNC table.
