Operating manual.
CNC 8060
CNC 8065
11.
PROFILE EDITOR
Define a new profile, enlarge an existing one or import one from a file.
·210·
(REF: 1807)
different Polar origin. Being the incremental coordinates active, the editor will show the
symbol
next to the affected data.
Cartesian coordinates.
The data definition area shows the following data.
Polar coordinates.
The data definition area shows the following data.
Start a new profile.
This softkey may be used to add a new profile to the current one, for example to define a
pocket with islands.
Modify the last element of the profile.
This softkey may be used to modify the last element added to the profile.
Undo the last operation.
This softkey may be used to "undo" the last operation made.
Save and continue.
To save the profile and continue editing. Using this key does not require that the profile be
completed.
Data. Information
X1, Y1 Coordinates of the starting point of the section on each axis of the active plane
at the editor.
X2, Y2 Coordinates of the end point of the section on each axis of the active plane at
the editor.
Xc, Yc Coordinates of the center of the section on each axis of the active plane at the
editor.
Radius Radius of the arc.
Tangency Tangency with the previous section of the profile.
Data. Information
r1, 1 Radius and Polar angle of the section's starting point.
r2, 2 Radius and Polar angle of the section's end point.
rc, c Radius and Polar angle of the section's center point.
Radius Radius of the arc.
Tangency Tangency with the previous section of the profile.
