Operating manual.
CNC 8060
CNC 8065
3.
HOW TO OPERATE THE CNC
Detailed description of the CNC status bar
·66·
(REF: 1807)
G Active work mode (automatic, manual, etc.) selected screen number and total number
of screens available. System clock.
By clicking on the active work mode, the CNC shows the list of available pages and which
ones are visible.
H Active CNC message.
For each channel, it shows the last message activated by the program that is running.
The window shows the last message of the active channel. If there are messages in other
channels, it will highlight the "+" sign next to the message window. To display the list of
active messages, press the key combination [CTRL]+[O] or click on the CNC message
line.
The list of messages shows, next to each message, the channel where it is active.
I PLC messages.
