RX2530 M4 Upgrade and Maintenance Manual 113
6.2 Redundant power supply
Figure 34: PSU bays
6.2.1 Installing a hot-plug PSU
I The procedure of installing an AC PSU or a DC PSU differs only in
connecting the power cord.
I A second PSU of the same type as the already existing PSU can be
installed while the system is in operation.
When the PSU is plugged in, a CSS error is generated, as an
information, and will be cleared as soon as the power cord is connected.
The system is automatically configured as a system with redundant
power supply.
6.2.1.1 Preliminary steps
No steps needed.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver (for DC PSU -48 V)
