RX2530 M4 Upgrade and Maintenance Manual 123
6.3 Fujitsu battery unit (FJBU)
6.3.1 Installing the FJBU
6.3.1.1 Preliminary steps
No steps needed.
6.3.1.2 Removing the dummy cover
Figure 44: Removing a dummy cover
Ê Press in on both release latches (1) and remove the dummy cover (2).
V CAUTION!
Keep the dummy cover for future use. If a FJBU is removed and not
immediately replaced by a new one, a dummy cover must be reinstalled
in the bay to comply with applicable EMC regulations and satisfy cooling
requirements.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
