RX2530 M4 Upgrade and Maintenance Manual 163
Hard disk drive (HDD) / solid state drive (SSD)
7.4.7 Installing 2.5-inch PCIe SSD modules
I This procedure is valid, if the PCIe SSD module is controlled by an
onboard controller or by a Retimer card.
For more information, see the "NVMe User Guide".
I If the PCIe SSD module is controlled by a RAID controller of the PRAID
EP5x0i family, the PCIe SSD module can be installed during operation
(hot-plug), see section "Installing 2.5-inch HDD/SSD modules" on
page 156.
7.4.7.1 Preliminary steps
Ê Locate the correct drive bay, see section "2.5-inch HDD/SSD configurations"
on page 148.
Ê Depending on your operating system (see the "NVMe User Guide"),
"Shutting down the server" on page 49.
7.4.7.2 Removing a 2.5-inch HDD/SSD dummy module
Ê Remove the 2.5-inch HDD/SSD dummy module, see section "Removing a
2.5-inch HDD/SSD dummy module" on page 156.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
