RX2530 M4 Upgrade and Maintenance Manual 189
Hard disk drive (HDD) / solid state drive (SSD)
7.4.14 Upgrading configuration from up to four to up to
eight 2.5-inch HDDs/SSDs
V CAUTION!
All data on all HDDs/SSDs in the array will be lost when deleting the
RAID array! Be sure to back up your data before deleting a RAID array.
For more information, see the "ServerView Suite RAID Management"
user guide.
I After installing or removing an additional backplane, never forget to
change the system information using the Chassis ID Prom Tool.
7.4.14.1 Preliminary steps
Ê "Shutting down the server" on page 49
Ê "Disconnecting the power cord" on page 50
Ê "Getting access to the component" on page 52
7.4.14.2 Removing the ODD lock
Ê If an ODD has been installed, remove the ODD, see section "Removing the
ODD" on page 339.
Figure 103: Removing the ODD lock (A)
Ê Push the ODD lock in direction of the arrow.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: tool-less
