RX2530 M4 Upgrade and Maintenance Manual 339
13.1.3 Removing the ODD
13.1.3.1 Preliminary steps
Ê "Removing backup and optical disk media" on page 80
Ê "Suspending BitLocker functionality" on page 77
Ê "Shutting down the server" on page 49
Ê "Disconnecting the power cord" on page 50
Ê "Getting access to the component" on page 52
13.1.3.2 Removing the ODD
Figure 248: Disconnecting the cables from the ODD
Ê Disconnect the ODD power cable and the SATA cable from the ODD.
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Tools: – Torx Plus 6 screw driver (not valid for Japan)
– Phillips PH1 / (+) No. 1 screw driver (Japan)
