RX2530 M4 Upgrade and Maintenance Manual 67
Basic hardware procedures
4.8 Handling riser modules
Figure 18: Numbering riser modules
I As an option, a full height riser module can be installed. In this case the
slot 3 is not available and slot 4 can be equipped with a full height
expansion card.
1 Riser module 1, offers slot 1 and slot 2
2 Riser module 2, offers slot 3
3 Riser module 3, offers slot 4
