70 Upgrade and Maintenance Manual RX2530 M4

Basic hardware procedures

4.9 Handling chassis foams

I The system can be equipped with two chassis foams. The chassis foams

must be removed for cabling purposes.

Figure 22: Position chassis foams

chassis foam 1

chassis foam 2
