RX2530 M4 Upgrade and Maintenance Manual 137
Hard disk drive (HDD) / solid state drive (SSD)
7.3 3.5-inch HDD configurations
I The HDD bays can be equipped with 3.5-inch HDD modules or 2.5-inch
HDD/SSD modules, see section "2.5-inch HDD/SSD and 3.5-inch
installation frame" on page 133.
7.3.1 Configuration with up to four HDD modules
Figure 55: Configuration with up to four 3.5-inch HDDs
Position Logical drive number ServerView RAID Manager display name
[0] 0 Vendor Product (0)
[1] 1 Vendor Product (1)
[2] 2 Vendor Product (2)
[3] 3 Vendor Product (3)
