260 Upgrade and Maintenance Manual RX2530 M4
Expansion cards and backup units
9.6.2.3 Preparing the FBU
Ê Prepare the FBU, see section "Preparing the FBU" on page 254.
Figure 179: Connecting the FBU cable to the FBU
Ê Connect the cable end on the FBU to the FBU cable as shown.
9.6.2.4 Installing the FBU
Figure 180: Riser module with shoulder screw caps
