Hard disk drive (HDD) / solid state drive (SSD)
Configuration with RAID controller:
Figure 67: Configuration with up to eight HDDs/SSDs (RAID controller)
Position Logical drive number ServerView RAID Manager display name
[0] 0 Vendor Product (0)
[1] 1 Vendor Product (1)
[2] 2 Vendor Product (2)
[3] 3 Vendor Product (3)
[4] 4 Vendor Product (4)
[5] 5 Vendor Product (5)
[6] 6 Vendor Product (6)
[7] 7 Vendor Product (7)
