220 Upgrade and Maintenance Manual RX2530 M4

Expansion cards and backup units

Figure 133: Slots of riser module 1

Pos. Component

1 Slot 1 is an internal slot only; dedicated slot for modular RAID

controller

2 Slot 2

top cover
