10 FAN 7/8 Power connector for system fan 7 and 8
11 FAN 5/6 Power connector for system fan 5 and 6
12 LC1 Connector for LC pump for CPU 1
13 FAN 3/4 Power connector for system fan 3 and 4
14 FAN 1/2 Power connector for system fan 1 and 2
15 SMB4 (I2C5) OOB (Out-Of-Band) connector for HDD backplane
16 SATA 4-7
SATA HDD connector
17 SATA 0-3 SATA HDD connector
18 HDD LED Connector for HDD LED cable (e.g. PRAID EP5xxi)
19 VPP CPU 1 Connector for VPP cable (e.g. Retimer controller)
20 VROC
21 TPM Connector for optional TPM
22 M.2 SSD2 M.2 slot 2
23 M.2 SSD1 M.2 slot 1
24 SERIAL (COM1) Connector for optional serial interface
25 micro SD iRMC microSD card
26 PCIe Port 0 RED Oculink connector
27 PCIe Port 1
YELLOW
Oculink connector
28 VPP CPU 2 Connector for VPP cable (e.g. Retimer controller)
29 PSU2 Power connector for PSU 2
30 ROC Connector for Dual microSD 64GB Enterprise cable
31 PSU1 Power connector for PSU 1
Pos. Print Description
