3RX2530 M4
List of used cables
Cable plan
Name
Number
Routing
C1
C1
CBL FRONT PANEL
T26139-Y4015-V302
System board to Front panel
C2
CBL_PWR_4P_2x4P
T26139-Y3959-V308
500 + 250 mm System board to HDD BPL
R-Shape and L-Shape
C3
CBL_PWR_ODD_470
T26139-Y3990-V303
System board to ODD
C4
CBL_Data_ODD_770
T26139-Y4028-V305
System board to ODD
C5
CBL_Front_VGA
T26139-Y3994-V302
System board to front VGA modul
C6
CBL_OOB_2BP
T26139-Y4015-V609
System board to HDD Bpl
C7
CBL_PWR_4P_4P
T26139-Y3959-V309
System board to 3,5” HDD Bpl
C8
CBL-Front_USB
T26139-Y3999-V503
System board to Front panel
C9
T26139-Y4040-V52
T26139-Y4040-V52
System board to 3,5” HDD backplane
C10
CBL_DATA2.5_ONB_R
T26139-Y4040-V53
System board to 4x 2,5” HDD backplane R-
Shape
C11
CBL_DATA2.5_ONB_L
T26139-Y4040-V54
System board to 4x 2,5” HDD backplane L-
Shape
C12
CBL_SASHD_DATA3.5
T26139-Y4040-V21
Cougar 4 to 3,5” HDD backplane
Second Source C25
C13
CBL HOST-BP 540
T26139-Y4040-V9
Cougar 4 to 4x 2,5” HDD backplane R-
Shape or SAS Expander
Second Source C26 /since 04/2018
C14
CBL HOST-BP 700
T26139-Y4040-V11
Cougar 4 to 4x 2,5” HDD backplane L-
Shape
Second Source C27 /since 04/2018
C15
CBL_FLEXP_560
T26139-Y4042-V6
System board to Front panel 10x 2,5
C16
CBL_FBU03_550
T26139-Y4031-V102
FBU to PRAID EP4xxi and PRAID EP420e
( 3,5” Chassis)
C17
CBL_FBU_750
T26139-Y4031-V105
FBU to PRAID EP4xxi ( 2,5” Chassis)
C18
CBL_PWR_HDD_10X2.5
T26139-Y3959-V310
System board to 10x BPL 550 mm
4Pin to 6Pin
C19
CBL_OCU_OCU_720
T26139-Y4050-V3
Retimer 1(Slot3) to 10xCombo and NVME
BPL
C20
CBL_VPP_250
T26139-Y4015-V610
System board to PCIe-Retimer (Pegatron)
