Fujitsu PRIMERGY RX2530 M4

RX2530 M4 Upgrade and Maintenance Manual 55
Basic hardware procedures
Figure 6: Removing the server from the rack
Ê Release the locking bars on both rack rails (1).
Ê Lift the server out of the rack rails (2) and place it on an even surface.
햲
햳
