Garmin G2000 - Supplemental Flight Data; Temperature Displays

190-01263-01 Rev. A
Garmin G2000 Pilot’s Guide for the Cessna T240
97
Flight instruments
sYstem
OVerVieW
Flight
instruments
eis
AuDiO PAnel
& Cns
Flight
mAnAgement
hAZArD
AVOiDAnCe
AFCs
ADDitiOnAl
FeAtures
APPenDiCes inDeX
2.3 SupplementAl Flight dAtA
In addition to the flight instruments, the PFD also displays various supplemental information, including
temperatures, wind data, and Vertical Navigation (VNV) indications.
temperAture diSplAyS
The Outside Air Temperature (OAT) and deviation from International Standard Atmosphere (ISA) temperature
are displayed to the left of the HSI on the PFD. Both are displayed in degrees Celsius (°C).
Figure 2-42 Outside Air Temperature and ISA Temperature
