Garmin G2000 - Section 4 Audio and Cns; Overview

190-01263-01 Rev. A
Garmin G2000 Pilot’s Guide for the Cessna T240
121
Audio And CnS
SYSTEM
oVERViEW
FLiGHT
inSTRuMEnTS
EiS Audio & CnS
FLiGHT
MAnAGEMEnT
HAZARd
AVoidAnCE
AFCS
AddiTionAL
FEATuRES
APPEndiCES indEX
Section 4 Audio And cnS
4.1 overview
The Communication/Navigation/Surveillance (CNS) system includes the Audio Controller, communication
radios, navigation radios, and Mode S transponder. The System Overview Section provides a block diagram
description of the Audio and CNS system interconnection.
The Touchscreen Controller provides primary tuning of the communication transceivers and microphone and
receiver audio selection. The Audio Controller includes an intercom system (ICS) between the pilot, copilot, and
passengers, a marker beacon receiver, and a COM clearance recorder.
The Mode S transponder is controlled with the Touchscreen Controller. The Transponder Button is located in
the upper right of the touchscreen, right below the XPDR IDENT Button. The Transponder Button displays the
active four-digit code, mode, and reply status (Figure 4-3).
