Garmin G2000 - Engine Parameters

Garmin G2000 Pilot’s Guide for the Cessna T240
190-01263-01 Rev. A112
engine indication SyStem
SyStem
oVerVieW
fligHt
inStrUmentS
eiS
aUdio panel
& cnS
fligHt
management
HaZard
aVoidance
afcS
additional
featUreS
appendiceSindeX
engine parameterS
MANIFOLD PRESSURE GAUGE
The Manifold Pressure (MAP) Gauge shows engine manifold pressure from ten to forty inches of Mercury.
Figure 3-6 Manifold Pressure Gauge
TACHOMETER GAUGE
The Tachometer (RPM) Gauge measures the propeller speed from zero to 3000 revolutions per minute
(RPM).
Figure 3-7 Tachometer Gauge
CRUISE POWER DISPLAY
The Cruise Power (CRU % PWR) Display shows the percentage of available power from 51% to 91% as a
digital readout. This value is based calculations from engine RPM, manifold pressure, pressure altitude, and
outside air temperature (OAT). The system displays dashes ‘--’ instead of a readout when the percentage of
available power is outside of the range mentioned above.
Figure 3-8 Cruise Power Display
