190-01263-01 Rev. A
Garmin G2000 Pilot’s Guide for the Cessna T240
269
Flight ManageMent
SYSteM
OVeRVieW
Flight
inStRUMentS
eiS
aUDiO Panel
& CnS
Flight
ManageMent
haZaRD
aVOiDanCe
aFCS
aDDitiOnal
FeatUReS
aPPenDiCeS inDeX
A waypoint must be adjacent to its parent waypoint in the flight plan, so the system limits the along-track
distance to less than the length of the leg before or after the selected waypoint. If the selected waypoint is the
active waypoint, the distance is limited to less than the distance to go to the active waypoint. Assigning an along
track offset to a leg with indeterminate length is not permitted. An along track offset is not allowed at or after
the final approach fix of an approach.
The along track offset distance cannot be modified once entered, but the altitude can be modified. If the
along track offset distance must be changed, the existing along track offset waypoint must be deleted and a new
one created with the new offset distance.
Waypoint
Options
Select
Button
Figure 5-116 Along Track Offset
(After) +
Button
Waypoint
Selected
(Before) -
Button
Along
Track
Waypoint
Button
Along Track Offset
Waypoint
Along Track Offset
Waypoint Altitude
Entering an along track offset distance:
1) From Home, touch Flight Plan
2) Touch a waypoint options button to display the Waypoint Options Screen.
3) Touch the Along Track Waypoint Button to bring up the Along Track Waypoint Offset Screen.
4) Use the keypad to select the distance in the range of 1 to 999 nm (limited by leg distances).
5) Touch the (Before) - Button or (After) - Button to select the offset waypoint direction.
4) Touch the Enter Button to insert the offset waypoint into the active flight plan.
