Touch the Legend Button on the SiriusXM Weather Settings Screen to display weather legend(s) for enabled
weather product(s). Scroll as necessary to view the information, then touch Back or Home.
Figure 6-22 Surface Analysis and City Forecast Legend
FREEZING LEVELS
Freezing Level data shows the color-coded contour lines for the altitude and location at which the first
isotherm is found (Figure 6-23). When no data is displayed for a given altitude, the data for that altitude has
not been received, or is out of date and has been removed from the display.
Figure 6-23 Freezing Level Weather Product
Displaying Freezing Level information:
1) From Home, touch Weather > Weather Selection > SiriusXM Weather > SiriusXM Settings.
2) Scroll as needed in the Overlays window and touch the Freezing Level Button.
Touch the Legend Button on the SiriusXM Weather Settings Screen to display weather legend(s) for enabled
weather product(s). Scroll as necessary to view the information, then touch Back or Home.
Figure 6-24 Freezing Level Legend
