8-142 Section 8-4 - Software Installation
8-4-2-4 DMC Checks (DMC User Only)
NOTE: DMC Cable is supplied only as an option.
1.) Check DMC Cable (USB to Serial Bridge).
2.) Plug in the Cable as shown on the right side of the USB port.
3.) Ensure
USB to Serial Bridge port is recognized by the system.
4.) Trackball to My computer icon and left click
5.) Right click on
Properties.
6.) Right click on the
Hardware tab.
7.) Right click on the device manager in the middle right of the hardware tab window.
Figure 8-195 DMC Cable
DMC Cable
Plug on the right

GE LOGIQ P5 Specifications

General

Power Supply	100-240VAC, 50/60Hz
Display	15" LCD
Doppler Modes	Color Doppler, Power Doppler
Imaging Modes	B-Mode, M-Mode
Probes	Convex, Linear, Phased Array
Applications	Abdominal, Vascular, Cardiac, OB/GYN, Small Parts, Musculoskeletal
Connectivity	DICOM, USB, Ethernet
Probe Connectors	3
Portability	Mobile
Operating Temperature	10°C to 40°C
Relative Humidity	30%
