DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
8-150 Section 8-4 - Software Installation
8-4-4-3 Setting Printer Preferences (cont’d)
5.) Select removable disk or media that the printer setting was saved -> Click “Open”.
6.) Click the “OK” until all printer windows are closed.
7.) If Sony D895 is used, repeat the above step 1 and 3, then set the parameters below in the layout
tab and advanced tab.
Figure 8-206 Printer set restore
Parameters Descriptions
Orientation Portrait or Landscape
Paper size Paper size
Scaling Rate of length and width
Table 8-56 Parameters

GE LOGIQ P5 Specifications

General

Power Supply	100-240VAC, 50/60Hz
Display	15" LCD
Doppler Modes	Color Doppler, Power Doppler
Imaging Modes	B-Mode, M-Mode
Probes	Convex, Linear, Phased Array
Applications	Abdominal, Vascular, Cardiac, OB/GYN, Small Parts, Musculoskeletal
Connectivity	DICOM, USB, Ethernet
Probe Connectors	3
Portability	Mobile
Operating Temperature	10°C to 40°C
Relative Humidity	30%
