Equipment Setup

If the paper

size is

Then

A4 Move the two paper latches to the position of "A4", and fasten the screws

using a PH 1x150 mm screwdriver.

5864335-001-1  MAC

™

5 A4/MAC

™

5 A5/MAC

™

5 Lite 29
