Record an ECG or Rhythm
Item Name Description
2 Preview of ECG patient
report
Displays the preview of the ECG patient report. If a patient report
contains multiple pages, a part of another page displays on the
right side of the screen. Press the left and right arrows on the
screen to navigate from one page to another.
For more information on the report formats and the standard
layout of the ECG patient report, see ECG Report Formats on page
287.
3 Reject icon Select the Reject icon to return to the live waveform display in the
Acquisition screen.
4 Accept icon Select the Accept icon to accept the preview of the ECG patient
report and save it in the Files list. The accepted ECG patient report
is refreshed and displayed for review with additional options.
To accept or reject the ECG preview, perform the steps as follows:
1. Review the patient report and Hookup Advisor status.
2. If the CRIT- Critical Value Notifications option is enabled on the device, and one
or more critical values are detected during ECG acquisition, a window opens on
top of the screen displaying critical value notifications in the order in which they
are detected.
3. Select Continue to acknowledge each notification.
If you try to perform other functions such as accessing the Settings or Service
screen prior to accepting or rejecting the ECG, a message displays indicating that
the ECG is not saved, and the preview will be lost if you navigate to the screen.
Select one of the options as follows:
• If you select Continue, the preview will be lost.
• If you select Cancel, you can proceed to accept or reject the ECG preview.
4. Accept or reject the ECG preview based on the Hookup Advisor status.
74  MAC
â„¢
5 A4/MAC
â„¢
5 A5/MAC
â„¢
5 Lite 5864335-001-1
