System
Recording series of tests
256 A0534-30.0 HBM: public MGCplus
LV1-LV4: The trigger is in response to a limit value (High: LED on, recording
program is started; Low: LED off)
External trigger: The trigger is in response to an external signal (remote
control 7 on the connection board).
Channel
Source channel for the trigger definitions.
Signal
Source signal for the trigger definition.
Trigger:
OK
Cancel
Start Trigger 1
Type:
Channel:
Mode:
Level:
Start Trigger 1
Off
1
greater than
0.000000% ... 0.000000% ...
Gross Signal:
Define trigger
Start Trigger 1
Start Trigger 2
Start Trigger 3
Start Trigger 4
Stop Trigger 1
Stop Trigger 2
Stop Trigger 3
Stop Trigger 4
Start sampling rate trg.
Stop sampling rate trg.
Off
Measured value level
Measured value band
LV1
LV2
LV3
LV4
External trigger
