80
Setting Application Settings
(2) Setting measurement conditions on individual dialog boxes
Screen display method (For more information, see p. 24):
AC measurement: (SET screen) BASIC tab>LIST key
DC measurement: (SET screen) Rdc tab>LIST key
1
Select the measurement range you wish
to congure with the  keys.
To apply the settings to all
measurement ranges, turn
this setting on and then
congure the settings.
(To congure measurement
ranges individually, turn it
off.)
*Touch EXIT to return to the
previous screen.
2
Select the setting you wish to congure.
"Setting measurement conditions on a single
screen" (p. 81)
3
Set the conditions and touch the SET
key.
SPEED Sets the measurement speed (p. 54).
AVG Congures averaging (p. 56).
DELAY Sets the trigger delay (p. 63).
(BASIC tab screen only)
SYNC Congures the trigger synchronous out-
put (p. 64) (BASIC tab screen only)
Touch the CANCEL key to cancel the set-
tings and close the dialog box.
4
Touch the EXIT key twice.
Displays the measurement screen.
Settings are the same as those described
in"3.4 Setting Measurement Conditions (basic
settings)" (p. 43).
