D1 Servo Drive User Manual Operation Principles
HIWIN MIKROSYSTEM CORP. 3-17
MD20UE01-2109
Number
Name
Description
66
I6
Input 6
67
I9
Input 9 (Pulse command)
68
I10
Input 10 (Pulse command)
69
I11
Input 11
70
I12
Input 12
81
O1
Output 1
82
O2
Output 2
83
O3
Output 3
84
O4/BRK
Output 4 (For brake signal)
