4.10 Accessories of D1 servo drive
(1) Motor power cable
Table4.10.1
Product Name
Model
Description
Motor Power
Cable
LMACSD
Applicable linear motor: LMS, LMSA, LMC-EFE and LMC-EFF
series
Supports motor over temperature signal. (Withstand voltage 500
V)
LMACSK
Applicable linear motor: LMCA, LMCB, LMCC, LMCD, LMCE,
LMC-EFC and LMT series
Supports motor over temperature signal.
LMACSL
Applicable linear motor: LMCF series
Supports motor over temperature signal.
LMACSF
Torque motor power cable
Applicable torque motor: TMS, TMN and TMY series
Do not support motor over temperature signal.
LMACST
Applicable linear motor: LMSA series
Supports motor over temperature signal (Withstand voltage 600
V).
LMACSJ
Applicable linear motor: LMF and LMFA series
Supports two over temperature signals, KTY and PTC.
(Applicable continuous current is below 24 Arms.)
LMACSQ
Applicable linear motor: LMFL and LMFAL series
Supports two over temperature signals, KTY and PTC.
( is motor model.)(Applicable continuous current is between
24 to 35 Arms.)
LMACSP
Applicable linear motor: LMF and LMFA series
Supports one over temperature signal, PTC.
 stands for cable length (Unit: m), refer to the tables below.
a LMACSD
Table4.10.2
b LMACSK
Table4.10.3

02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
Cable
Length
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
Cable
Length
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
