(2) Phase initialization
If the servo drive is used with incremental encoder, when its power is turned on for the first time, the
procedure of finding electrical angle or phase initialization must be done. For HIWIN linear servo
motor, electrical angle can be successfully found without moving the motor for a long distance.
Another commonly-used method for phase initialization is by using Hall sensor. Normally phase
initialization and enabling can be completed via an output signal from controller (such as I1 input of
D1 servo drive).
3.11 Basic physical quantities
Table3.11.1
Number
Name
Description
1
Feedback position
Feedback position
2
Reference position
Position command
3
Target position
Target position
4
Position error
Position error
10
Feedback velocity
Feedback velocity
11
Reference velocity
Velocity command
12
Velocity error
Velocity error
20
Reference acceleration
Acceleration command
30
Actual current
Actual current
31
Command current
Current command
40
Analog command
Voltage command (From controller)
41
Bus voltage
Line voltage
42
Servo voltage percentage
Servo voltage
43
SIN-analog encoder
Sine signal of analog encoder
44
COS-analog encoder
Cosine signal of analog encoder
45
PWM command
Torque/force/velocity command (From controller)
46
Digital hall bits
Digital Hall signal
50
Amplifier temperature
Servo drive temperature
51
Soft-thermal accumulator
Temperature estimation by software
52
I2T accumulator
I2T estimation
61
I1
Input 1
62
I2
Input 2
63
I3
Input 3
64
I4
Input 4
65
I5
Input 5 (Motor over temperature signal)
