Hiwin D1 - Connector Specifications

Wiring D1 Servo Drive User Manual
4-4 HIWIN MIKROSYSTEM CORP.
MD20UE01-2109
4.1.2 Connector specifications
Table4.1.2.1
Connector
Specification
Manufacturer
Wire Gauge Range
Note
Connector for AC
main power cable
European standard
4-pin 7.5 mm
pluggable connector
(Female)
Wago
Part number:
721-204/026-000
22 - 12 AWG
Suggested:
12 AWG, 600 V
Wiring tool:
Wago 231-131
Connector for
motor power cable
European standard
4-pin 5.0 mm
pluggable connector
(Female)
Wago
Part number:
721-104/026-000
22 - 12 AWG
Suggested:
12 AWG, 600 V
Wiring tool:
Wago 231-131
Connector for
regenerative
resistor
European standard
3-pin 5.0 mm
pluggable connector
(Male)
Wago
Part number:
723-603
22 - 14 AWG
Suggested:
14 AWG, 600 V
Wiring tool:
Wago 231-131
Connector for
control power
European standard
3-pin 5.0 mm
pluggable connector
(Female)
Wago
Part number:
721-103/026-000
22 - 14 AWG
Suggested:
18 AWG
Wiring tool:
Wago 231-131
Connector for
RS232
communication
6-pin module
connector
(RJ-11 type)
Connector for
control signals
26-pin,
.050" Mini D Ribbon
(MDR), standard
solder connector
3M
Part number: 10126-3000
24 - 30 AWG
Molex
Part number: 0543062619
26-pin,
.050" Mini D
connector,
molded insulation
displacement (IDC)
type
Molex
Part number:
0523162619
28 AWG
Back cover
3M
Part number:
10326-52F0-008
Molex
Part number:
0543310261
Connector for
feedback signals
20-pin,
.050" Mini D Ribbon
(MDR), standard
solder connector
3M
Part number:
10120-3000
24 - 30 AWG
Molex
Part number:
0543062019
20-pin,
.050" mini D
connector,
molded insulation
displacement (IDC)
type
Molex
Part number:
0523162019
28 AWG
Back cover
3M
Part number:
10320-52F0-008
Molex
Part number:
0543310201
