D1 Servo Drive User Manual Wiring
HIWIN MIKROSYSTEM CORP. 4-31
MD20UE01-2109
(2) Feedback signal cable
A. D1--2: linear motor
Table4.10.10
Product Name
Model
Description
Feedback
Signal Cable
LMACEC
For Renishaw analog optical scale and HIWIN
magnetic scale, D type 15 pin connector
Supports motor over temperature signal.
LMACEJ
For Renishaw analog optical scale and HIWIN
magnetic scale, D type 15 pin connector
Supports motor over temperature signal and digital
Hall signal.
 stands for cable length (Unit: m), refer to the tables below.
a LMACEC
Table4.10.11

01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
Cable
Length
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
b LMACEJ
Table4.10.12

03
04
05
06
07
08
09
10
Cable
Length
3
4
5
6
7
8
9
10
B. D1--2: TMS, TMNE, TMNEH and TMNR torque motors
Table4.10.13
Product Name
Model
Description
Feedback
Signal Cable
LMACEAA
For JENA analog encoder
Applicable torque motor: TMS, TMNE,
TMNEH and TMNR series
Supports motor over temperature signal.
Do not support Hall signal.
 is motor model.
LMACEAM
For JENA analog encoder
Applicable torque motor: TMS, TMNE,
TMNEH and TMNR series
Supports motor over temperature signal and Hall
signal.
 is motor model.
