Panther System

Operator’s Manual

AW-17791-001 Rev. 002 (EN)

355

Appendix C. System Messages

Code Message Possible Cause Solution

272.000.00012 {0} in sample rack

{1}, position {2} has

not been registered.

System software

error.

1. Collect logs using

the Send Logs

feature (see Send

Logs on page

259).

2. Backup the

database.

3. Contact Hologic

Technical

Support.

272.000.00013 No Calibrator

Masterlot found for

assay {0}.

System software

error.

1. Collect logs using

the Send Logs

feature (see Send

Logs on page

259).

2. Backup the

database.

3. Contact Hologic

Technical

Support.

272.000.00014 No Control

Masterlot found for

assay {0}.

System software

error.

1. Collect logs using

the Send Logs

feature (see Send

Logs on page

259).

2. Backup the

database.

3. Contact Hologic

Technical

Support.
