Honeywell UDC3500 User Manual

Configuration
86 UDC3500 Universal Digital Controller Product Manual 3/07
Function Prompt
Lower Display
Selections or
Range of Setting
Upper Display
Parameter
Definition
MATH K
0.001 to 1000 floating
WEIGHTED AVERAGE RATIO OR MASS FLOW
ORIFICE CONSTANT (K) FOR MATH
SELECTIONS—Only applicable for algorithms
W AVG or General Math selections √MuDIV,
√MULT, MuDIV, or MULT.
CALC HI
–999. To 9999. Floating
(in engineering units)
CALCULATED VARIABLE HIGH SCALING
FACTOR FOR INPUT ALGORITHM 1—Used only
when Summer, Input Hi/Lo, or one of the General
Math functions was selected as the Input Algorithm.
See Note 2.
CALC LO
–999. To 9999. Floating
(in engineering units)
CALCULATED VARIABLE LOW SCALING
FACTOR FOR INPUT ALGORITHM 1—Used only
when Summer, Input Hi/Lo, or one of the General
Math functions was selected as the Input Algorithm.
See Note 2.
ALG1 INA
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
LP1OUT
LP2OUT
IN AL1
IN AL2
ALGORITHM 1, INPUT A SELECTION—
Represents one of the following selections:
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
LOOP 1 OUTPUT—Should not be used for Three
Position Step Control applications
LOOP 2 OUTPUT—Should not be used for Three
Position Step Control applications
INPUT ALGORITHM 1
INPUT ALGORITHM 2
ALG1 INB
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
LP1OUT
LP2OUT
IN AL1
IN AL2
ALGORITHM 1, INPUT B SELECTION—
Represents one of the following selections:
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
LOOP 1 OUTPUT—Should not be used for Three
Position Step Control applications
LOOP 2 OUTPUT—Should not be used for Three
Position Step Control applications
INPUT ALGORITHM 1
INPUT ALGORITHM 2
