Configuration
3/07 UDC3500 Universal Digital Controller Product Manual 89
Function Prompt
Lower Display
Selections or
Range of Setting
Upper Display
Parameter
Definition
ALG2 INA
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
LP1OUT
LP2OUT
IN AL1
IN AL2
ALGORITHM 2, INPUT A SELECTION—
Represents one of the following selections:
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
LOOP 1 OUTPUT—Should not be used for Three
Position Step Control applications
LOOP 2 OUTPUT—Should not be used for Three
Position Step Control applications
INPUT ALGORITHM 1
INPUT ALGORITHM 2
ALG2 INB
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
LP1OUT
LP2OUT
IN AL1
IN AL2
ALGORITHM 2, INPUT B SELECTION—
Represents one of the following selections:
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
LOOP 1 OUTPUT—Should not be used for Three
Position Step Control applications
LOOP 2 OUTPUT—Should not be used for Three
Position Step Control applications
INPUT ALGORITHM 1
INPUT ALGORITHM 2
ALG2 INC
NONE
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
LP1OUT
LP2OUT
IN AL1
IN AL2
ALGORITHM 2, INPUT C SELECTION—
Represents one of the following selections:
NONE
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
LOOP 1 OUTPUT—Should not be used for Three
Position Step Control applications
LOOP 2 OUTPUT—Should not be used for Three
Position Step Control applications
INPUT ALGORITHM 1
INPUT ALGORITHM 2
ALG2BIAS
-999 to 9999 floating (in
engineering units)
INPUT ALGORITHM 2 BIAS—Does not apply to
selections: FFWR2, FFWM2, HI SEL or LO SEL.
