Honeywell UDC3500 User Manual

Configuration
3/07 UDC3500 Universal Digital Controller Product Manual 101
Function Prompt
Lower Display
Selections or
Range of Setting
Upper Display
Parameter
Definition
NAND
NAND—NOT AND is the best way to describe the
NAND gate. It is an inverted AND gate. When Input
A and Input B are ON
, the Output is OFF.
NAND
INPUT A
INPUT B
OUTPUT (Y)
A B
Y
0
1
0
0
0
1
1
1
01
1
1
X OR
X OR (EXCLUSIVE OR)—The operation of this gate
is, as its name implies, Exclusively “OR”. If Input A
OR Input B is ON
, the Output will be ON. If Input A
and Input B are ON
or OFF, the Output will be OFF.
X OR
INPUT A
INPUT B
OUTPUT (Y)
A B
Y
0
1
0
0
0
1
1
0
01
1
1
XNOR
X NOR EXCLUSIVE NOR)—The EXCLUSIVE NOR
is an inverted EXCLUSIVE OR. If Input A and Input
B are ON
or OFF, the Output will be ON.
XNOR
INPUT A
INPUT B
OUTPUT (Y)
A B
Y
0
1
0
0
0
1
1
0
0
1
1
1
